| PANJANG X LEBAR X TINGGI | 1980 x 880 x 1305 mm |
|---|---|
| JARAK SUMBU | 1285 mm |
| GROUND CLEARANCE | 175 mm |
| TINGGI TEMPAT DUDUK | 810 mm |
| BERAT KOSONG | 104 kg |
| TIPE SUSPENSI DEPAN | Upside Down |
| TIPE SUSPENSI BELAKANG | Monoshock Unitrack System |
| REM DEPAN | Disc Brake 270 mm |
| REM BELAKANG | Disc Brake 220 mm |
| UKURAN BAN DEPAN | 70/100-19 |
| UKURAN BAN BELAKANG | 90/100-16 |
| KAPASITAS TANGKI | 5.5 Liter |
| TIPE MESIN | 4 Langkah SOHC |
|---|---|
| DIAMETER LANGKAH | 62.0 x 49.5 mm |
| KOPLING | Manual Multiplate Wet Clutch |
| VOLUME LANGKAH | 149.4 cc |
| DAYA MAKSIMAL | 7.5KW / 7500 rpm |
| TORSI MAKSIMAL | 9.8 N.m / 7000 rpm |
| GIGI TRANSMISI | 5 Kecepatan |
| POLA PENGOPERASIAN GIGI | 1-N-2-3-4-5 |
| STARTER | Electric Starter & Kick Starter |
| ACCU | 12V-5Ah |
| SISTEM PENGAPIAN | AC-CDI |
